Användningsområden
- Ljudisolationsmätning
- Efterklangsmätning
- Ljudabsorbtionsmätning
Toppegenskaper
- Speciellt designad för byggakustikmätningar
- Låg vikt och robust konstruktion
- Inbyggd brusgenerator
Output: Short-circuit and over-temperature protected
Output connector: Speakon NL4MP
Output power:
500 WRMS RMS into 4ohm
250 WRMS RMS into 8ohm
THD+N < 0.1% The built-in LP and HP filters ensure that the output power matches the Norsonic Nor275 and Nor276 series of dodecahedron loudspeakers Peak power: >1 kWPEAK into 4ohm
Output current: Maximum 35 A
Input: Balanced input to avoid ground loops and cross talk to signal cables
Input connector: XLR
Input sensitivity: 1.0 VRMS
Input impedance: 10 k//220 pF
Dimensions: (D x W x H) 275 × 110 × 246 [mm] 11 x 4,3 x 9,7 [inch]
Weight: 3,5 kg
Temperature: –20 to +35 °C
Rel. Humidity: 0–90%
Enclosure class: IP20
Mains: 220 VAC (±10%) or 110 VAC (±10%)
Fuse: T 3,15A (220 V), T 6A (110 V)
EMC and Safety Standards: EN 55103-1, EN 55103-2, IEC 61340-5 part 1&2, IEC 61010, FCC part 15b part 1&2
CE Conformity: EMC compliance according to EN 50081-1 and EN 50082-1, Safety according to EN 61010-1-1993 and Machine directive 89/392
